Microsoft Tunnel is a VPN gateway solution for Microsoft Intune that runs in a Docker container on Linux and allows access to on-premises resources from iOS/iPadOS and Android Enterprise devices using modern authentication and Conditional Access.

This article introduces the tunnel, how it works, and its architecture.

If you're ready to deploy the Microsoft Tunnel, see Prerequisites for the Microsoft Tunnel, and then Configure the Microsoft Tunnel.

Overview of Microsoft Tunnel

Microsoft Tunnel Gateway installs to a Docker container that runs on a Linux server. The Linux server can be a physical box in your on-premises environment or a virtual machine that runs on-premises or in the cloud. You'll deploy a Microsoft Tunnel client app and Intune VPN profiles to your iOS and Android devices to enable them to use the tunnel to connect to corporate resources. When the tunnel is hosted in the cloud, you’ll need to use a solution like Azure ExpressRoute to extend your on-premises network to the cloud.

Through the Microsoft Endpoint Manager admin center, you’ll:

  • Download the Microsoft Tunnel installation script that you’ll run on the Linux servers.
  • Configure aspects of Microsoft Tunnel Gateway like IP addresses, DNS servers, and ports.
  • Deploy VPN profiles to devices to direct them to use the tunnel.
  • Deploy the Microsoft Tunnel client apps to your devices.

Through a Microsoft Tunnel client app, iOS/iPadOS and Android Enterprise devices:

  • Use Azure Active Directory (Azure AD) to authenticate to the tunnel.
  • Are evaluated against your Conditional Access policies. If the device isn’t compliant, then it won’t have access to your VPN server or your on-premises network.

To connect to the tunnel, devices use one of the following Microsoft Tunnel client apps, depending on device platform. The apps are available from each platforms app store:

  • Android: Microsoft Defender for Endpoint, which includes support for Microsoft Tunnel.
  • iOS/iPadOS: Microsoft Tunnel standalone app.

You can install multiple Linux servers to support Microsoft Tunnel, and combine servers into logical groups called Sites. Each server can join a single Site. When you configure a Site, you’re defining a connection point for devices to use when they access the tunnel. Sites require a Server configuration that you’ll define and assign to the Site. The Server configuration is applied to each server you add to that Site, simplifying the configuration of more servers.

To direct devices to use the tunnel, you create and deploy a VPN policy for Microsoft Tunnel. This policy is a device configuration VPN profile that uses Microsoft Tunnel for its connection type.

Important

Prior to support for using Microsoft Defender for Endpoint as the tunnel client app, a standalone tunnel client app was available in preview and used a connection type of Microsoft Tunnel (standalone client). As of June 14 2021, both the standalone tunnel app and standalone client connection type are deprecated and drop from support 60 days later on August 14 2021.

iOS/iPadOS continues to use the standalone client app, which remains in preview, and a connection type of Microsoft Tunnel (standalone client).

Features of the VPN profiles for the tunnel include:

  • A friendly name for the VPN connection that your end users will see.
  • The site that the VPN client connects to.
  • Per-app VPN configurations that define which apps the VPN profile is used for, and if it's always-on or not. When always-on, the VPN will automatically connect and is used only for the apps you define. If no apps are defined, the always-on connection provides tunnel access for all network traffic from the device.
  • Manual connections to the tunnel when a user launches the VPN and selects Connect.
  • On-demand VPN rules that allow use of the VPN when conditions are met for specific FQDNs or IP addresses. (iOS/iPadOS)
  • Proxy support (iOS/iPadOS, Android 10+)

Server configurations include:

  • IP address range – The IP addresses that are assigned to devices that connect to a Microsoft Tunnel.
  • DNS servers – The DNS server devices should use when they connect to the server.
  • DNS suffix search.
  • Split tunneling rules – Up to 500 rules shared across include and exclude routes. For example, if you create 300 include rules, you can then have up to 200 exclude rules.
  • Port – The port that Microsoft Tunnel Gateway listens on.

Site configuration includes:

  • A public IP address or FQDN, which is the connection point for devices that use the tunnel. This address can be for an individual server or the IP or FQDN of a load-balancing server.
  • The Server configuration that is applied to each server in the Site.

You assign a server to a Site at the time you install the tunnel software on the Linux server. The installation uses a script that you can download from within the admin center. After starting the script, you’ll be prompted to configure its operation for your environment, which includes specifying the Site the server will join.

To use the Microsoft Tunnel, devices will need to install a Microsoft Tunnel client app. You get the applicable app from the iOS/iPadOS or Android app stores and deploy it to users.

Architecture

The Microsoft Tunnel Gateway runs in Docker containers that run on Linux servers.

Components:

Dell Connect Tunnel Download Mac
  • A – Microsoft Intune.
  • B- Azure Active Directory (AD).
  • C – Linux server with Docker.
    • C.1 - Microsoft Tunnel Gateway.
    • C.2 – Management Agent.
    • C.3 – Authentication plugin – Authorization plugin, which authenticates with Azure AD.
  • D – Public facing IP or FQDN of the Microsoft Tunnel, which can represent a load balancer.
  • E – Mobile Device Management (MDM) enrolled device.
  • F – Firewall
  • G – Internal Proxy Server (optional).
  • H – Corporate Network.
  • I – Public internet.

Actions:

  • 1 - Intune administrator configures Server configurations and Sites, Server configurations are associated with Sites.
  • 2 - Intune administrator installs Microsoft Tunnel Gateway and the authentication plugin authenticates Microsoft Tunnel Gateway with Azure AD. Microsoft Tunnel Gateway server is assigned to a site.
  • 3 - Management Agent communicates to Intune to retrieve your server configuration policies, and to send telemetry logs to Intune.
  • 4 - Intune administrator creates and deploys VPN profiles and the Tunnel app to devices.
  • 5 - Device authenticates to Azure AD. Conditional Access policies are evaluated.
  • 6 - With split tunnel:
    • 6a - Some traffic goes directly to the public internet.
    • 6b - Some traffic goes to your public facing IP address for the Tunnel.
  • 7 - The Tunnel routes traffic to your internal proxy (optional) and your corporate network.

Additional details:

  • Conditional Access is done in the VPN client and based on the cloud app Microsoft Tunnel Gateway. Non-compliant devices won’t receive an access token from Azure AD and can't access the VPN server. For more information about using Conditional Access with Microsoft Tunnel, see Use Conditional Access with the Microsoft Tunnel.

  • The Management Agent is authorized against Azure AD using Azure app ID/secret keys.

  • The Tunnel Gateway server uses NAT to provide addresses to VPN clients that are connecting to the corporate network.

Next steps

-->

Configuration of the Microsoft Tunnel VPN gateway for Microsoft Intune is a multi-step process. The process includes use of the Microsoft Endpoint Manager admin center, and running a script to install the tunnel software on a Linux server, which must run Docker. While this article walks you through the steps to configure the Microsoft Tunnel for use, configuration of Linux and Docker is beyond the scope of this content.

When installing the Microsoft Tunnel, you’ll start in the Microsoft Endpoint Manager admin center to define both Servers and Sites. Then, you run the tunnel installation script on a Linux server that has Docker installed. The script installs containers to support the tunnel server, pulls information from Intune about the tunnel Sites you’ve defined for your tenant, and then installs the Tunnel server. The Linux server can run on-premises or in the cloud. Depending on your environment and infrastructure, extra configurations and software, like Azure ExpressRoute, might be needed.

Before you continue, be sure to complete the following tasks:

  • Review and Configure prerequisites for Microsoft Tunnel.
  • Run the Microsoft Tunnel readiness tool to confirm your environment is ready to support use of the tunnel.

After your prerequisites are ready, return to this article to begin installation and configuration of the tunnel.

Create a Server configuration

Use of a Server configuration lets you create a configuration a single time and have that configuration used by multiple servers. The configuration includes IP address ranges, DNS servers, and split-tunneling rules. Later, you’ll assign a Server configuration to a Site, which automatically applies that configuration to each server that joins that Site.

To create a Server configuration

  1. Sign in to Microsoft Endpoint Manager admin center > Tenant administration > Microsoft Tunnel Gateway > select theServer configurationstab > Create new.

  2. On the Basics tab, enter a Name and Description(optional) and select Next.

  3. On the Settings tab, configure the following items:

    • IP address range: IP addresses within this range are leased to devices when they connect to Tunnel Gateway. For example, 169.254.0.0/16.

    • DNS servers: These servers are used when a DNS request comes from a device that's connected to Tunnel Gateway.

    • DNS suffix search(optional): This domain is provided to clients as the default domain when they connect to Tunnel Gateway.

    • Split tunneling(optional): Include or exclude addresses. Included addresses are routed to Tunnel Gateway. Excluded addresses aren’t routed to Tunnel Gateway. For example, you might configure an include rule for 255.255.0.0 or 192.168.0.0/16.

      Split tunneling supports a total of 500 rules between both include and exclude rules. For example, if you configure 300 include rules, you can only have 200 exclude rules.

    • Server port: Enter the port that the server listens to for connections.

  4. On the Review + create tab, review the configuration, and then select Create to save it.

Create a Site

Sites are logical groups of servers that host Microsoft Tunnel. You’ll assign a Server configuration to each Site you create. That configuration is applied to each server that joins the Site.

To create a Site configuration

  1. Sign in to Microsoft Endpoint Manager admin center > Tenant administration > Microsoft Tunnel Gateway > select theSitestab > Create.

  2. On the Create a site pane, specify the following properties:

    • Name: Enter a name for this Site.

    • Description(optional)

    • Public IP address or FQDN: Specify a public IP address or FQDN, which is the connection point for devices that use the tunnel. This IP address or FQDN can identify an individual server or a load-balancing server. The IP address or FQDN must be resolvable in public DNS and the resolved IP address must be publicly routable.

    • Server configuration: Use the drop-down to select a server configuration to associate with this Site.

    • Automatically upgrade servers at this site: If Yes, servers upgrade automatically when an upgrade is available. If No, upgrade is manual and an administrator must approve an upgrade before it can start.

      For more information, see Upgrade Microsoft Tunnel.

    • Limit server upgrades to maintenance window: If Yes, server upgrades for this site can only start between the start time and end time specified. There must be at least an hour between the start time and end time. When set to No, there is no maintenance window and upgrades start as soon as possible depending on how Automatically upgrade servers at this site is configured.

      When set to Yes, configure the following options:

      • Time zone – The time zone you select determines when the maintenance window starts and ends on all servers in the site, regardless of the time zone of individual servers.
      • Start time – Specify the earliest time that the upgrade cycle can start, based on the time zone you selected.
      • End time - Specify the latest time that upgrade cycle can start, based on the time zone you selected. Upgrade cycles that start before this time will continue to run and can complete after this time.

      For more information, see Upgrade Microsoft Tunnel.

  3. Select Create to save the Site.

Install Microsoft Tunnel Gateway

Before installing Microsoft Tunnel Gateway on a Linux server, configure your tenant with at least one Server configuration, and then create a Site. Later, you’ll specify the Site that a server joins when you install the tunnel on that server.

Use the script to install Microsoft Tunnel

  1. Download the Microsoft Tunnel installation script by using one of the following methods:

    • Download the tool directly by using a web browser. Go to https://aka.ms/microsofttunneldownload to download the file mstunnel-setup.

    • Sign in to Microsoft Endpoint Manager admin center > Tenant administration > Microsoft Tunnel Gateway, select the Servers tab, select Create to open the Create a server pane, and then select Download script.

    • Use a Linux command to get the readiness tool directly. For example, on the server where you’ll install the tunnel, you can use wget or curl to open the link https://aka.ms/microsofttunneldownload.

      For example, to use wget and log details to mstunnel-setup during the download, run wget --output-document=mstunnel-setup https://aka.ms/microsofttunneldownload

  2. To start the server installation, run the script as root. For example, you might use the following command line: sudo chmod +x ./mstunnel-setup. The script always installs the most recent version of Microsoft Tunnel.

    Important

    For the U.S. government cloud, the command line must reference the government cloud environment. To do so, run the following comands to add intune_env=FXP to the command line:

    1. Run sudo chmod +x ./mstunnel-setup
    2. Run sudo intune_env=FXP ./mstunnel-setup

    Tip

    If you stop the installation and script, you can restart it by running the command line again. Installation continues from where you left off.

    When you start the script, it downloads container images from Docker, and creates necessary folders and files on the server.

    During setup, the script will prompt you to complete several admin tasks.

  3. When prompted by the script, accept the license agreement (EULA).

  4. Review and configure variables in the following files to support your environment.

    • Environment file: /etc/mstunnel/env.sh. For more information on these variables, see Environment variables in the reference for Microsoft Tunnel article.
  5. When prompted, copy the full chain of your Transport Layer Security (TLS) certificate file to the Linux server. The script displays the correct location to use on the Linux server.

    The TLS certificate secures the connection between the devices that use the tunnel and the Tunnel Gateway endpoint. The certificate must have the IPI address or FQDN of the Tunnel Gateway server in its SAN.

    The private key will remain available on the machine where you create the certificate signing request for the TLS certificate. This file must be exported with a name of site.key.

    Install the TLS certificate and private key. Use the following guidance that matches your file format:

    • PFX:

      • The certificate file name must be site.pfx. Copy the certificate file to /etc/mstunnel/private/site.pfx.
    • PEM:

      • The full chain (root, intermediate, end-entity) must be in a single file named site.crt. If your using a certificate issued by a public provider like Digicert, you have the option of downloading the complete chain as a single .pem file.

      • The certificate file name must be *site.crt. Copy the full chain certificate into /etc/mstunnel/certs/site.crt. For example: cp [full path to cert] /etc/mstunnel/certs/site.crt

        Alternatively, create a link to the full chain cert in /etc/mstunnel/certs/site.crt. For example: ln -s [full path to cert] /etc/mstunnel/certs/site.crt

      • Copy the private key file into /etc/mstunnel/private/site.key. For example: cp [full path to key] /etc/mstunnel/private/site.key

        Alternatively, create a link to the private key file in /etc/mstunnel/private/site.key. For example: ln -s [full path to key file] /etc/mstunnel/private/site.key This key shouldn't be encrypted with a password. The private key file name must be site.key.

  6. After setup installs the certificate and creates the Tunnel Gateway services, you’re prompted to sign in and authenticate with Intune. The user account must have either the Intune Administrator or Global Administrator roles assigned. The account you use to complete the authentication must have an Intune license. The credentials of this account aren't saved and are only used for initial sign-in to Azure Active Directory. After successful authentication, Azure app IDs/secret keys are used for authentication between the Tunnel Gateway and Azure Active Directory.

    This authentication registers Tunnel Gateway with Microsoft Endpoint Manager and your Intune tenant.

    1. Open a web browser to https://Microsoft.com/devicelogin and enter the device code that’s provided by the installation script, and then sign in with your Intune admin credentials.

    2. After Microsoft Tunnel Gateway registers with Intune, the script gets information about your Sites and Server configurations from Intune. The script then prompts you to enter the GUID of the tunnel Site you want this server to join. The script presents you with a list of your available sites.

    3. After you select a Site, setup pulls the Server configuration for that Site from Intune and applies it to your new server to complete the Microsoft Tunnel installation.

  7. After the installation script finishes, you can navigate in Microsoft Endpoint Manager admin center to the Microsoft Tunnel Gateway tab to view high-level status for the tunnel. You can also open the Health status tab to confirm that the server is online.

Deploy the Microsoft Tunnel client app

To use the Microsoft Tunnel, devices need access to a Microsoft Tunnel client app. You can deploy the tunnel client app to devices by assigning it to users. The following apps are available:

Android:

  • Microsoft Defender for Endpoint - Download Microsoft Defender for Endpoint for use as the Microsoft Tunnel client app from the Google Play store. See Add Android store apps to Microsoft Intune.

    When you use Microsoft Defender for Endpoint as your tunnel client application and as a mobile threat defense (MTD) application, see Use Microsoft Defender for Endpoint for MTD and as the Microsoft Tunnel client app for important configuration guidance.

iOS/iPadOS:

  • For iOS/iPadOS, download the Microsoft Tunnel client app from the Apple App Store. See Add iOS store apps to Microsoft Intune.

For more information on deploying apps with Intune, see Add apps to Microsoft Intune.

Create a VPN profile

After the Microsoft Tunnel installs and devices install the Microsoft Tunnel client app, you can deploy VPN profiles to direct devices to use the tunnel. To do so, you’ll create VPN profiles with one of the following connection types:

  • Android: Microsoft Tunnel

    The Android platform supports routing of traffic through a per-app VPN and split tunneling rules independently, or at the same time.

    Note

    Prior to support for using Microsoft Defender for Endpoint as the tunnel client app, a standalone tunnel client app was available in preview and used a connection type of Microsoft Tunnel (standalone client). As of June 14 2021, both the standalone tunnel app and standalone client connection type are deprecated and drop from support 60 days later on August 14 2021.

  • iOS/iPadOS: Microsoft Tunnel (standalone client)

    The iOS platform supports routing traffic by either a per-app VPN or by split tunneling rules, but not both simultaneously. If you enable a per-app VPN for iOS, your split tunneling rules are ignored.

Android

  1. Sign in to Microsoft Endpoint Manager admin center > Devices > Configuration profiles > Create profile.

  2. For Platform, select Android Enterprise. For Profile select VPN for either Corporate-Owned Work Profile or Personally-Owned Work Profile, and then select Create.

    Note

    Android Enterprise dedicated devices aren't supported by the Microsoft Tunnel.

  3. On the Basics tab, enter a Name and Description(optional) and select Next.

  4. For Connection type select Microsoft Tunnel, and then configure the following details:

    • Base VPN:

      • For Connection name, specify a name that will display to users.
      • For Microsoft Tunnel Site, select the tunnel Site that this VPN profile will use.
    • Per-app VPN:

      • Apps that are assigned in the per-app VPN profile send app traffic to the tunnel.
      • On Android, launching an app won't launch the per-app VPN. However, when the VPN has Always-on VPN set to Enable, the VPN will already be connected and app traffic will use the active VPN. If the VPN isn't set to be Always-on, the user must manually start the VPN before it can be used.
      • To enable a per-app VPN, select Add and then browse to custom or public apps you’ve imported to Intune.
    • Always-on VPN:

      • For Always-on VPN, select Enable to set the VPN client to automatically connect and reconnect to the VPN. Always-on VPN connections stay connected. If Per-app VPN is set to Enable, only the traffic from apps you select go through the tunnel.
    • Proxy:

      • Configure proxy server details for your environment.

    For more information about VPN settings, see Android Enterprise device settings to configure VPN

    Important

    For Android Enterprise Personally-Owned Work Profile devices that use Microsoft Defender for Endpoint as a Microsoft Tunnel client application and as a MTD app, you must use custom settings to configure Microsoft Defender for Endpoint instead of using a separate app configuration profile. Use of custom settings is optional for all other platforms.

  5. On the Assignments tab, configure groups that will receive this profile.

  6. On the Review + create tab, review the configuration, and then select Create to save it.

iOS

  1. Sign in to Microsoft Endpoint Manager admin center > Devices > Device Configuration > Create profile.

  2. For Platform, select iOS/iPadOS, and then for Profile select VPN, and then Create.

  3. On the Basics tab, enter a Name and Description(optional) and select Next.

  4. For Connection type select Microsoft Tunnel (standalone client), and then configure the following items:

    • Base VPN:

      • For Connection name, specify a name that will display to users.
      • For Microsoft Tunnel Site, select the tunnel Site that this VPN profile will use.
    • Per-app VPN:

      • To enable a per-app VPN, select Enable. Additional configuration steps are required for iOS per-app VPNs. When the per-app VPN is configured, your split tunneling rules are ignored by iOS.

        For more information, see Per-App VPN for iOS/iPadOS.

    • On-Demand VPN Rules:
      Define on-demand rules that allow use of the VPN when conditions are met for specific FQDNs or IP addresses.

      For more information, see Automatic VPN settings

    • Proxy:

      • Configure proxy server details for your environment.

Use custom settings for Microsoft Defender for Endpoint

Intune supports Microsoft Defender for Endpoint as both a MTD app and as the Microsoft Tunnel client application on Android Enterprise devices. If you use Defender for Endpoint for both the Microsoft Tunnel client application and as a MTD app, you can use custom settings in your VPN profile for Microsoft Tunnel to simplify your configurations. Use of custom settings in the VPN profile replaces the need to use a separate app configuration profile.

For devices enrolled as Android Enterprise personally-owned work profile that use Defender for Endpoint for both purposes, you must use custom settings instead of an app configuration profile. On these devices, the app configuration profile for Defender for Endpoint conflicts with Microsoft Tunnel and can prevent the device from connecting to Microsoft Tunnel.

If you use Microsoft Defender for Endpoint for MTD but not for Microsoft Tunnel, then you continue to use the app configuration profile to configure Microsoft Defender for Endpoint.

Add app configuration support for Microsoft Defender for Endpoint to a VPN profile for Microsoft Tunnel

Use the following information to configure the custom settings in a VPN profile to configure Microsoft Defender for Endpoint in place of a separate app configuration profile:

Configuration keyValue typeConfiguration valueInformation about the setting
vpnIntegerOptions:
1 - Enable (default)
0 - Disable
Set a to enable to allow the Microsoft Defender for Endpoint anti-phishing capability to use a local VPN.
antiphishingIntegerOptions:
1 - Enable (default)
0 - Disable
Set to enable to turn on Microsoft Defender for Endpoint anti-phishing. When disabled, the anti-phishing capability is turned off.
defendertoggleIntegerOptions:
1 - Enable (default)
0 - Disable
Set to enable to use Microsoft Defender for Endpoint. When disabled, no Microsoft Defender for Endpoint functionality is available.

Upgrade Microsoft Tunnel

Intune periodically releases updates to the Microsoft Tunnel server. To stay in support, tunnel servers must run the most recent release, or at most be one version behind.

By default, after a new upgrade is available Intune automatically starts the upgrade of tunnel servers as soon as possible, at each of your tunnel sites. To help you manage upgrades, you can configure options that manage the upgrade process:

  • You can allow automatic upgrade of servers at a site, or require admin approval before upgrades being.
  • You can configure a maintenance window which limits when upgrades at a site can start.

For more information about upgrades for Microsoft Tunnel, including how to view tunnel status and configure upgrade opotons, see Upgrade Microsoft Tunnel.

Update the TLS certificate on the Linux server

You can use the ./mst-cli command-line tool to update the TLS certificate on the server:

  1. Copy the new certificate to /etc/mstunnel/certs/site.crt
  2. Copy the private key to /etc/mstunnel/private/site.key
  3. Run: mst-cli import_cert

For more information about mst-cli, see Reference for Microsoft Tunnel.

Uninstall the Microsoft Tunnel

To uninstall the product, run ./mst-cli uninstall from the Linux server as root.

Download Dell Connect

Next steps

Download Dell Mobile Connect Pc

Use Conditional Access with the Microsoft Tunnel
Monitor Microsoft Tunnel
